ABB UPS External battery module 11RT G2 3 kVA UPS from ABB is an online double-conversion UPS engineered for reliable power protection in critical single-phase applications. Designed for IT infrastructure, automation, and industrial environments, it ensures consistent performance and maximum uptime.
SKU: 4NWP100205R0001
Availability: UAE, Abu Dhabi, Dubai and Africa
upsbase.com is a leading value added distributor and authorized dealer for UPS and VRLA products in the UAE / Africa market.
ON-TIME
DELIVERY
SECURE
CHECKOUT
EASY
RETURNS
UAE BASED
SUPPORT TEAM
ABB UPS External battery module 11RT G2 3 kVA UPS is part of ABB PowerValue 11 RT G2 UL (1–3 kVA) and uses Online Double Conversion (VFI) topology to deliver clean, regulated power for critical single-phase loads.
| Topology | Online Double Conversion (VFI) |
|---|---|
| Rated Capacity | 3 kVA |
| Output Rated Power | 2.88 kW |
| Parallel Configuration | No |
| Input (Nominal) | 100 / 110 / 115 / 120 / 125 VAC |
| Input Voltage Range | 50–150 VAC (de-rating to 60% @ 60V) |
| Input THDi | < 5% with full resistive load |
| Input Frequency Range | 45–55 Hz (50 Hz); 54–66 Hz (60 Hz) |
| Input Power Factor | ≥ 0.99 @ 100% load |
| Output (Rated Voltage) | 100 / 110 / 115 / 120 / 125 VAC |
| Output Voltage Regulation | ± 1% |
| Output Voltage Distortion | < 2% |
| Overload Capability | Line: 1.5 s @ 140%; 30 s @ 130%; 300 s @ 110% Battery: 1.5 s @ 140%; 10 s @ 130%; 120 s @ 110% |
| Nominal Frequency | 50 / 60 Hz |
| Crest Factor | 3:1 |
| Efficiency | Up to 90% (double conversion); Up to 96% (ECO mode) |
| Battery Type | VRLA (valve regulated lead-acid) |
| Battery Configuration | 1×6 x 9Ah |
| Charging Current | 1 / 2 (default) / 4 / 6 A |
| Operating Temperature | 0°C to 40°C |
| Relative Humidity | 0% to 95% (non-condensing) |
| Protection Rating | IP20 |
| Standards | UL 1778 5th / CSA-C22.2 No.107.2; FCC Part 15 Class A; IEC/EN 62040-3 |
| Weight (w/o batteries) | 27.5 kg |
| Dimensions (W × H × D) | 438 × 88 × 630 mm |
